Cisco Catalyst3850-24L Dubai

Rating

Cisco Catalyst3850-24L Dubai

The Cisco Catalyst 3850 Series Switches support five optional network modules for uplink ports. The default switch configuration does not include the network module.

Category:

Description

Cisco Catalyst3850-24L Network Switch Dubai

The Cisco Catalyst3850-24L Dubai is a stackable enterprise level switch and integrated with 24 Ethernet UPOE ports in LAN Base feature set. It supports up to 800W UPOE per switch and 60W per port. The Cisco Catalyst 3850 Series Switches support five optional network modules for uplink ports. The default switch configuration does not include the network module.

The Cisco Catalyst3850-24L Dubai is equipped with Cisco’s popular StackPower technology. StackPower is an innovative power sharing and redundancy technology available on the Cisco 3850 series of switches. This configuration allows members of the stack to share in one of two power pooling topologies. The first, power sharing mode, aggregates then distributes the power among the stack. Power is dynamically allocated where it’s needed. The second, redundant mode, polls the stack, identifies the supply with the greatest wattage then reserves its use for failure. Power is then allocated to the stack from the remainder of the supplies. Once the reserved power supply is activated, the stack migrates to power sharing mode automatically. This technology eliminates the need for an external RPS unit and allows users to simply add another power supply for either redundancy or additional power to the pool.

Features :

  • AutoQoS (Automatic QoS)
  • DHCP (Dynamic Host Configuration Protocol)
  • DTP (Dynamic Trunking Protocol)
  • PAgP (Port Aggregation Protocol)
  • LACP (Link Aggregation Control Protocol)
  • MDIX (Automatic media-dependent interface crossover)
  • UDLD (Unidirectional Link Detection Protocol)
  • SDM (Switching Database Manager)
  • ARP (Local Proxy Address Resolution Protocol
  • IGMP (Internet Group Management Control Protocol)
  • IGMP Filtering
  • VLAN Registration
  • VTP (VLAN Trunking Protocol)
  • Dynamic VLAN assignment
  • RSPAN Remote Switch Port Analyzer
  • Layer 2 Traceroute
  • TFTP (Trivial File Transfer Protocol)
  • NTP (Network Timing Protocol)
  • Equal-cost routing and load balancing (Layer 3)
  • EEM (Embedded Event Manager)
  • SLAs (IP Service-level Agreements)
  • Private VLAN’s
  • Private VLAN Edge
  • Multidomain Authentication
  • Port Based ACL’s
  • SSH (Secure Shell Protocol)
  • Kerberos
  • SNMPv3
  • SPAN
  • TACACS+ and Radius Authentication
  • MAC Address Notification
  • Multilevel security on console access
  • BPDU (Bridge Protocol Data Unit)
  • WTD (Weighted Tail Drop)

Technical Specs

Ports 48 x 10/100/1000 PoE+
Form Factor Desktop, Rack Mountable
Rack Units 1RU
Software IP Services
Subtype Gigabit Ethernet
Flash Memory 2 GB
PoE Budget 435W
Network Module Slots 1
VLAN IDs 4,000
Fans 3 Dual Redundant Fans
StackWise-480 Yes
Stacking Bandwidth 480 Gbps
Model # : WS-C3850-48P-E
Warranty : Lifetime Warranty
Condition : Refurbished
Weight : 17.40 lbs
Port Quantity 48
Series Catalyst 3850
Rack Units 1RU
OSI Layer L3
Stacking StackWise-480 & StackPower (IP Services to IP Services)
Deployment Pack No
Energy Efficient Yes
PoE Compatibility 802.3at PoE+
Ram 4GB
Flash 2GB
Ports 48 x Ethernet 10/100/1000
Switching Bandwidth 176 Gbps
Mac Addresses 32K
Operating Humidity 5 to 90% non-condensing
Storage Humidity 5 to 90% non-condensing
Stacking Bandwidth 480 Gbps
Unicast Routes 24K
Acoustic Noise
Available PoE Power 435W
Forwarding Rate Based On 64-Byte Packets 130.95 Mpps
Max Routed Ports Per 3850 Stack 208
Power Specifications 100-240VAC , 50-60Hz , 10-5A
Operating Temp 23 to 113°F (-5 to 45°C)
Storage Temp -40 to 158°F (-40 to 70°C)
Uplink Interfaces C3850-NM-4-1G, C3850-NM-2-10G, C3850-NM-4-10G
Max Active VLANS Depends on SDM template
Switched Virtual Interfaces (SVI’s) 1K
