Description
Fortinet Fortigate 401F Firewall Dubai
The Fortigate 401F Dubai Next-Generation Firewall (NGFW) utilizes artificial intelligence (AI) and machine learning to offer comprehensive threat protection on any scale. Gain enhanced visibility into your network, allowing you to identify applications, users, and devices preemptively before they pose a threat. With an integrated security fabric platform that incorporates advanced AI and machine learning capabilities, the Fortigate 401F Dubai provides extensive, intelligent, and automated security for your network. Safeguard your network comprehensively with cutting-edge edge protection, which includes web, content, and device security. Additionally, reduce complexity and mitigate risks in hybrid IT networks with network segmentation and secure SD-WAN. Universal Zero Trust Network Access (ZTNA) ensures controlled, verified, and streamlined user access to applications, reducing the risk of lateral threats by granting access solely to validated users. Benefit from ultra-fast threat protection and SSL inspection at the network edge without compromising performance using Fortigate 401F Dubai.
Fortigate 401F Highlights
- Gartner Magic Quadrant Leader for both Network Firewalls and WAN Edge Infrastructure.
- Security-Driven Networking FortiOS delivers converged networking and security.
- State-of-the-Art Unparalleled Performance with Fortinet’s patented / SPU / vSPU processors.
- Enterprise Security with consolidated AI / ML-powered FortiGuard Services.
- Deep Visibility into applications, users, and devices beyond traditional firewall techniques
Hardware Features
Trusted Platform Module (TPM)
The Fortigate 401F Dubai features a dedicated module that hardens physical networking appliances by generating, storing, and authenticating cryptographic keys. Hardware-based security mechanisms protect against malicious software and phishing attacks.
Access Layer Security
FortiLink protocol enables you to converge security and the network access by integrating the FortiSwitch into the FortiGate as a logical extension of the NGFW. These FortiLink enabled ports can be reconfigured as regular ports as needed.
Specifications
| Interfaces and Modules | |
| Hardware Accelerated GE RJ45 Interfaces | 16 |
| Hardware Accelerated GE SFP Slots | 8 |
| Hardware Accelerated 10GE SFP+ Slots | 4 |
| Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots | 4 |
| GE RJ45 Management Ports | 2 |
| USB Ports | 1 |
| RJ45 Console Port | 1 |
| Onboard Storage | 2x 480 GB SSD |
| Trusted Platform Module (TPM) | Yes |
| Included Transceivers | 2x SFP (SX 1 GE) |
| System Performance — Enterprise Traffic Mix | |
| IPS Throughput 2 | 12 Gbps |
| NGFW Throughput 2, 4 | 10 Gbps |
| Threat Protection Throughput 2, 5 | 9 Gbps |
| System Performance and Capacity | |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 79.5 / 78.5 / 70 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 79.5 / 78.5 / 70 Gbps |
| Firewall Latency (64 byte, UDP) | 4.19 μs / 2.5 μs* |
| Firewall Throughput (Packet per Second) | 105 Mpps |
| Concurrent Sessions (TCP) | 7.8 Million |
| New Sessions/Second (TCP) | 500 000 |
| Firewall Policies | 10 000 |
| IPsec VPN Throughput (512 byte) 1 | 55 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2000 |
| Client-to-Gateway IPsec VPN Tunnels | 50 000 |
| SSL-VPN Throughput 6 | 3.6 Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 5000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) 3 | 8 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) 3 | 6000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) 3 | 800 000 |
| Application Control Throughput (HTTP 64K) 2 | 28 Gbps |
| CAPWAP Throughput (HTTP 64K) | 65 Gbps |
| Virtual Domains (Default / Maximum) | 10 / 10 |
| Maximum Number of FortiSwitches Supported | 72 |
| Maximum Number of FortiAPs (Total / Tunnel) | 512 / 256 |
| Maximum Number of FortiTokens | 5000 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
