Grandstream GWN7706 Dubai

Rating

Grandstream GWN7706 Dubai

The Grandstream GWN7706 Dubai is an unmanaged network switch that provides a fast and affordable solution for expanding your home office or small business with high-speed Gigabit connectivity.

Description

Grandstream GWN7706 Network Switch Dubai

The Grandstream GWN7706 Dubai is an unmanaged network switch that provides a fast and affordable solution for expanding your home office or small business with high-speed Gigabit connectivity. These switches require no configuration or installation and can be desk or wall mounted. It also features auto MDI/MDIX functionality, eliminating the need for crossover cables. Each port of Grandstream GWN7706 Dubai supports auto-negotiation, allowing the switch to detect and adjust the connection speed of 10/100/1000 Mbps network devices to ensure compatibility and optimal performance. For your convenience, the PoE (Power-over-Ethernet) model is equipped with an IEEE 802.3af/compliant intelligent dynamic PoE output port. With this feature, you can power IP phones, IP cameras, WiFi access points and other PoE endpoints. Finally, the plug-and-play Grandstream GWN7706 Dubai is perfect for a home office or his SMB who needs an unmanaged network switch.

Technical Specifications

  • Gigabit Ports : 48
  • Enclosure : Metal
  • Mounting : Desktop/ Rack-Mount
  • Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p
  • Port Features :
    • 48× 10/100/1000 Mbps RJ-45 Ports
    • 2× SFP Fiber Ports
    • AUTO Negotiation, AUTO MDI/MDIX
  • Network Media : 1000Base-X, 1000Base-T/100Base-TX/10Base-Te, Half/Full-Duplex
  • LED Indicators :
    • Per port : Link/Activity Green
    • Per device : Power Green
  • Mac Address Table : 16K
  • Switching Capacity : 100Gbps
  • Jumbo Frame : 9KB
  • Advanced Features :
    • Mac Address Auto-Learning And Auto-Aging
    • IEEE 802.3x Flow Control
    • 802.1p/DSCP QoS
  • Power Adapter : Internal 100-240V AC,50/60Hz,40W
  • Max Power Consumption by Base System : 30W@220V/50Hz
  • Environmental :
    • Operating Temperature : 0 to 40 °C (32 to 104 °F)
    • Storage Temperature : -20 to 60 °C (-4 to 140 °F)
    • Operating Humidity : 10% to 90% Non-condensing
    • Storage Humidity : 10% to 90% Non-condensing
  • Dimensions (L x W x H) Unit : 440 x 200 x 44mm
  • Package : 500*335*89mm
  • Weight
    • Unit : 2.80Kg
    • Entire Package : 3.60Kg
  • Package :
    • 1x Switch
    • 1x 1.2m AC Cable
    • Rack-mounting Standard Brackets
    • 4x Rubber Fee
    • 1x GND Cable
    • 1x QIG
  • Compliance : FCC, CE, RCM, IC, UKCA
