Hanwha QRN430S CCTV Network Video Recorder
The Hanwha QRN430S Network Video Recorder (NVR), formerly recognized under the Samsung CCTV brand, is an innovative and efficient surveillance solution designed for small-scale security applications. Whether for residential, retail, or small business use, this high-performance 4-channel NVR ensures seamless video monitoring with user-friendly controls and robust security features.
Ultra-Clear 4K Video Recording for Precise Surveillance
Equipped with 8MP (4K) resolution support, the Hanwha QRN430S delivers exceptional image clarity for detailed monitoring and accurate incident review. This high-definition capability significantly enhances facial recognition, object identification, and overall security awareness, making it a reliable choice for professional surveillance.
Optimized Storage with H.265 Compression
With cutting-edge H.265 compression technology, the QRN430S efficiently reduces bandwidth usage and storage consumption while maintaining superior video quality. This advanced compression format enables extended recording periods, making it ideal for businesses or homeowners seeking cost-effective and long-term surveillance storage solutions.
Effortless Setup with PoE Technology
The built-in Power over Ethernet (PoE) ports simplify installation by delivering both power and data through a single cable. This plug-and-play setup minimizes cabling complexity, reducing installation time and costs. The intuitive user interface ensures easy management of live feeds, playback, and event alerts, even for those with minimal technical expertise.
Smart Security Features & Real-Time Alerts
The Hanwha QRN430S enhances security monitoring with intelligent video analytics, including motion detection, tampering alerts, and event-based notifications. These smart features provide real-time alerts, ensuring prompt response to potential security threats.
Versatile Display Compatibility & Flexible Viewing
Supporting both HDMI and VGA outputs, this NVR allows seamless connectivity with multiple display monitors. Users can easily configure their surveillance setup for real-time viewing, multi-screen monitoring, or remote playback, making it suitable for various environments.
Reliable Storage & Expandability
Designed for continuous video recording, the Hanwha QRN430S supports 1 HDD slot with up to 6TB storage capacity. This ensures secure retention of critical footage for extended periods, perfect for businesses that require long-term video archiving and compliance adherence.
Why Choose Hanwha QRN430S?
- Crystal-clear 4K resolution for superior video surveillance
- Advanced H.265 compression for optimized storage and bandwidth
- PoE support for easy plug-and-play installation
- Smart security analytics for real-time alerts and event detection
- Multi-output compatibility for flexible viewing options
- Expandable storage for long-term video retention
The Hanwha QRN430S 4-Channel NVR is the perfect blend of performance, reliability, and ease of use, making it an ideal choice for homeowners and businesses looking to enhance their security infrastructure with top-tier video surveillance technology.
Key Specifications:
- 4-channel recording support
- Resolution up to 8MP (4K)
- H.265/H.264 video compression
- Built-in PoE ports
- HDMI/VGA video outputs
- Advanced security analytics
- 1 HDD slot supporting up to 6TB
- Easy-to-use graphical interface
Specifications
| Display | |
| Network camera | |
| Network camera > Inputs | Max. 4CH |
| Network camera > Resolution | 8MP ~ CIF |
| Network camera > Protocols | SUNAPI, ONVIF |
| Decoding | |
| Decoding > Local Display | HDMI |
| Decoding > Multi Screen Display | [Local Monitor] 1/ 2V/ 2H/ 3V/ 4/ Sequence [Web] 1/ 2V/ 2H/ 3V/ 4 |
| Decoding > Resolution | [Local Monitor] 8M(30fps), 1080p(120fps), 720P(120fps), D1(120fps) |
| Performance | |
| Operating System | |
| Operating System > Embedded | Linux |
| Record | |
| Record > Compression | H.265, H.264, MJPEG |
| Record > Recording Bandwidth | Max. 40Mbps |
| Record > Resolution | 8MP ~ CIF |
| Record > Mode | Normal, Dual Stream, Schedule(Continuous/Event), Event (Pre/Post), Bookmark |
| Record > Event Trigger | Alarm Input, Video Loss, Camera Event(Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event |
| Record > Event Action | e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out |
| Search & Play | |
| Search & Play > Playback Bandwidth | Max. 32Mbps |
| Search & Play > User | Max. 4 Users (Local 1, Remote 3) |
| Search & Play > Simultaneous playback | Max. 16CH(Local 4CH, Remote 4CH per user) |
| Search & Play > Fisheye Dewarping | CMS |
| Search & Play > Mode | Date & Time(Calendar), Event list, Text Search, Smart Search |
| Search & Play > Resolution | CIF ~ 8MP |
| Search & Play > Playback Control | Fast/Slow Forward / Backward, Move one step Up / Down |
| Storage | |
| Storage > Supported HDD | Up to 6TB |
| Storage > HDD Slot | SATA 1ea(Max. 6TB) |
| Backup | |
| Backup > File backup | BU/Exe(GUI), JPG/AVI(Network) |
| Backup > Function | Multi channel(Up to 4CH) Play, Date-Time/Title display |
| Network | |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client) |
| DDNS | Hanwha DDNS |
| Transmission Bandwidth | Max. 50Mbps |
| Audio | |
| Audio > Input/Output | 4 CH(network) |
| Audio > Compression | G.711, G.726, AAC(16/48KHz) |
| Audio > Audio Communication | 2-Way |
| Max Remote Users | Search(3), Live Unicast(10), Multicast(20) |
| Security | IP address filtering, User access Log, 802.1x, Encryption Device certificate(Hanwha Techwin Root CA), Signed firmware |
| Web viewer | |
| Web viewer > Supported OS | Windows 10, macOS 10.13 |
| Web viewer > Supported browser | Google Chrome, Microsoft Edge, Mac Safari |
| Viewer Software | WAVE, SSM, Webviewer, Smart Viewer, Wisenet mobile Support CGI(SUNAPI) for integration to 3’rd party VMS |
| Functions | |
| Camera Setup | |
| Camera Setup > Register | Auto, Manual |
| Camera Setup > Item | IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup (4, 8 point polygon) Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage |
| PTZ | |
| PTZ > Control | Via GUI, Webviewer |
| PTZ > Preset | 300 Presets |
| Smart phone | |
| Smart phone > Support Model | iOS, Android |
| Smart phone > Protocol Support | RTP, RTSP, HTTP, CGI(SUNAPI) |
| Smart phone > Control | Live 4CH(Multi-Profile Support), Playback 4CH |
| Smart phone > Max. Remote Users | Search(3), Live Unicast(10) |
| Redundancy | |
| Redundancy > Failover | N+1 |
| Redundancy > ARB | Support |
| Easy configuration | P2P(QR code) |
| Interface | |
| Front | |
| Front > Indicator | Power, Record, Network |
| Storage | OK |
| Reset | Support |
| HDMI | 1EA 3840×2160 30Hz |
| Ethernet | PoE RJ-45(LAN, 10/100) 4 ea ,RJ-45 1ea (WAN, 10/100) |
| USB | 2EA(Front 1 x USB 2.0, Rear 1 x USB 2.0) |
| Power inlet | DC Adaptor |
| System | |
| Log | |
| Log > Log List | Max. 100,000 (System Log, Event Log each) |
| System Control | Mouse, Web |
| Language | English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese |
| Environmental | |
| Operating Temperature | 0°C to +40°C(32℉ to 104℉) |
| Operating Humidity | 20% ~ 85% RH |
| Electrical | |
| Power Input | 100 ~ 240 VAC ±10%; 50/60 Hz |
| Power Consumption | Max 52W(1HDD, PoE On) |
| PoE Budget | 35W |
| Mechanical | |
| Color / Material | Black / Metal |
| Dimension (WxHxD) | 300.0 x 47.1 x 208.4 mm (11.81 x 1.85 x 8.20 inch) |
| Weight | 1.03Kg (2.27lb) |
