- MS Teams Dual design
- 0 inch (480 x 800) capacitive touch screen
- Yealink Acoustic Shield Technology
- 2-ports USB 3.0 hub
- Wireless mobile phone charger (sold separately)
- Crystal speakerphone
- Supports busy light
- Microsoft Teams compatible
All Your Needs on the UC Workstation
The Yealink WH66 Dual Teams features Unified Communication Workstation providing users the possibility and flexibility to connect devices, and manage communications from a single device, and also act as a hub that integrate a full-duplex speakerphone, a 4-inch touch console, and a USB hub, which, together offer incredible set of features allowing you to meet, connect and collaborate seamlessly and intelligently.
Match Your Platform
Yealink WH66 Dual Teams supports broad compatibility of Yealink personal collaboration devices such as headsets, speakerphones and USB cameras, users can enjoy consistent call experience across unified communication platforms, which promises better communication quality, higher productivity and lower IT costs. Certified for Microsoft Teams, the devices designed with a dedicated Teams button for activating Microsoft Teams with one touch.
Be Heard Crystal Clearly
Yealink Acoustic Shield Technology, the two Microphones built in WH66 block the background noise automatically but ensure participant voice be heard clearly, greatly boost the communication efficiency.
No more EHS adapters needed
Yealink WH66 Dual Teams connect Yealink VoIP phone directly with one USB cable with DECT Wireless Technology. Also Built-In Bluetooth, supporting connect with cell phone and desk phone simultaneously. Integrated deeply with Yealink IP Phones, you can just feel the crystal call experience at the moment of wearing WH66. Also work with popular Unified Communication platforms, achieving all-round collaboration.
Yealink WH66 Dual Teams Specifications
General
- 0 inch (480 x 800) capacitive touch screen
- 2 feature buttons
- 1 Type-A USB 3.0 port
- Built-in Bluetooth 4.2
- Connectivity : USB 3.0 & 2 x Bluetooth devices
- Integrated busy light LED indicator
- Built-in hub : 2 Type-A USB 3.0 ports
- Boom arm adjustable : 320°
- Charging stand (for headset)
Battery
- Talk time : up to 13 hours (Mono), up to 14 hours (Dual)
- Standby time : 90 hours (Mono), 125 hours (Dual)
- Charging time : 2.5 hours (12 V / 2 A)
DECT
- Wireless range : up to 160 m/525 feet
- Secure DECT (level) : Step B – authentication – DSAA, encryption – DSC (64 bit)
- Cordless Advanced Technology : CAT-iq 2.0
Audio (Headset)
- Microphone type : dual microphone
- Microphone sensitivity : -44.0+/-3 dBV
- Microphone frequency range : 100 Hz-10 kHz
- Speaker size : Ф 28
- Speaker sensitivity : 92.5+/-3 dB, 0.179 V
- Speaker impedance : 32+/-4.8 Ω
- Speaker max output power : 10 mW
- Speaker frequency range : 20 Hz-10 kHz
- Speaker bandwidth – talk mode : wide band
- Speaker bandwidth – music mode : super wide band (Pending)
Audio (Base)
- Microphone type : ECM Omnidirectional microphone
- Microphone sensitivity : -38.0+/-2 dBV
- Microphone frequency range : 70 Hz-20 kHz
- Speaker size : 40 mm*20.8 mm
- Speaker sensitivity : 97+/-3 dB
- Speaker impedance : 4 Ω+/-15%
- Speaker max output power : 4 W
- Speaker frequency range : 160 Hz-20 kHz
Easy Call Management
- Answer/End/Reject a call
- Volume up/down
- Microphone mute
- Move the microphone boom arm up to mute, or down to un-mute
Package Features
- Package contents:
– WHB660 Base
– WHM621 Headset or WHD622 Headset
– Power Adapter
– 2* 1 m USB 3.0 Cable
– Quick Start Guide
- Optional accessories:
– Busy light BLT60
– Wireless Charger
– Bluetooth Dongle BT50
- WH 66 Mono : Base : 398 g, Headset : 80 g
- WH 66 Dual : Base : 398 g, Headset : 127 g
- W/CTN : WH 66 Mono : 10.46 kg; WH 66 Dual : 10.96 kg
- Gift box size : 255 mm*204 mm*135 mm
- Carton Meas : 698 mm*421 mm*265 mm
